ATTENTION: every seat MUST BE REPOSITIONED on the equipment from which it was re-
moved. Every seat has a regulation, depending of the carriage guide on which is mounted.
9. Reassemble the cup and the rear guard.
10. Sit down on the seat and row. Verify that the seat is stable.
6.7 EQUIPMENT CALIBRATION
Equipment calibration must be performed when:
• removing a component that interacts with the angle sensor board (e.g.knob);
• removing the U-I console;
• moving and/or replacing the Angle Sensor board;
• turning the knob, the levels shown on the display do not change correctly;
6.7.1 EQUIPMENT CALIBRATION
1. Connect the SKILLROW console with a power bank or a PC, through the USB-MINI USB cable;
the display switches on.
2. Long pressure SET buon + “DOWN ARROW” buon. So you enter in calibration mode.
3. It’s shown the number 1. Move the knob to level 1, then press SET. It’s shown the level 10. Wait
until it stops blinking.
4. Move the knob to level 10, then press SET. It’s shown the level 11. Wait until it stops blinking.
5. Move the knob to level 11, then press SET. It’s shown the level 12. Wait until it stops blinking.
6. Move the knob to level 12, then press SET. It’s shown the level 13. Wait until it stops blinking.
7. Move the knob to level 13, then press SET.
8. Appears the END screen. Then, it is shown the initial standard screen,
9. Disconnect the MINI USB cable from the console.
10. When the calibration is complete, put the protective cover back on the console MINI USB con-
nector.
The reference values of equipment calibration are the following: Level 1: 5299; Level 10: 2695; Level
11: 2322: Level 12: 1921; Level 13: 1446. This is only an indication about the order of magni-
tude of values. The values should decrease, with the increasing of the levels. If the values
are wrong, the cable that connects the angle sensor board to the CPU mainboard or the angle sensor
board could be broken.
SKILLROW:
Technical Service Guide - Rev. 1.1
Page 70
