7.8 DISASSEMBLING SEAT
1a - Loosen the lower screw of the rear guard (TOOL: 6mm Hexagonal wrench);
1b - Loosen the two lateral screws of the rear guard (TOOL: 3mm Hexagonal wrench);
1c - Remove the rear guard.
Figure 65
2. Remove the 4 screws, below highlighted (TOOL: Large Phillips screwdriver) and remove the
cap.
SKILLROW:
Technical Service Guide - Rev. 1.1
Page 90
