Figure 66
3. Remove the seat from the carriage guide.
4. Loosen the 4 screws of the seat guard (TOOL: 4mm Hexagonal Wrench). Then, remove the seat
guard.
 ATTENTION:becarefulnottodamagethewheelsoftheseat,duringtherepositionoftheseat.
 ATTENTION:everyseatMUSTBEREPOSITIONEDontheequipment from which it wasre-
moved.Everyseathasaregulation,dependingofthecarriageguideonwhichismounted.
Undertheseatthere’sonlyoneeccentric,asindicatedinthefollowinggure.Thegureservespure-
lyasanexample.
