6.6.4 THE DIFFICULTY LEVELS CHANGE ON THE DISPLAY, BUT THE PERCEIVED BY
THE USER DOESN’T CHANGE - POWER MODE
POWER MODE
The difficulty level changes on
the display, but the perceived
by the user doesn’t change.
1. Verify the presence of the spring [1]and that the spring
is hooked to the frame.
2. Verify the tension and the integrity of the cable [2].
3. Verify the integrity of knob [3]: tooth and pulley.
Make the necessary adjustments. Calibrate the
equipment. Problem solved?
OK. Problem Solved.
Replace the angle sensor board. Calibrate the
equipment. If necessary, replace the cable that
connects the angle sensor board to the CPU mainboard.
Calibrate the equipment.
Yes
No
Figure 28
The calibration of the equipment is described at the paragraph “6.7.1 equipment calibration”.
SKILLROW:
Technical Service Guide - Rev. 1.1
Page 60
