6.6 TROUBLESHOOTING
6.6.1 BRAKING IS NOT EFFICIENT: CLEANING THE FAN
If braking is not ecient, clean the fan.
Unscrew the screw (A); hold the grille (B) with one hand.
Unscrew the screws (C) to remove the grille (B).
Remove the protection (D).
Unscrew the screws (E) to remove the grille (F);
Use a vacuum cleaner to clean the grilles (B) and (F);
Unscrew the screws (G) and clean the fan with s vacuum cleaner;
Ret all the grilles;
Perform all the operations in reverse, following the indicated order. To ret the grille (B) it’s im-
portant to rst tighten the screws (C), and only at the end the screw (A).
Figure 23
