TECO JSDEP Series User Manual

9-9
※ JSMA-PM/PH motor dimension diagram
Motor Mode A LA D U W S G K L M
MA05 9 145 130 2.5 6 22 110 6 58 164.8
MH05 9 145 130 2.5 6 22 110 6 58 164.8
MA10 9 145 130 2.5 6 22 110 6 58 214.8
MB10 9 145 130 2.5 6 22 110 6 58 164.8
MC10 9 145 130 2.5 6 22 110 6 58 149.8
MH10 9 145 130 2.5 6 22 110 6 58 214.8
MA15 9 145 130 2.5 6 22 110 6 58 264.8
MB15 9 145 130 2.5 6 22 110 6 58 184.8
MC15 9 145 130 2.5 6 22 110 6 58 164.8
MB20 9 145 130 2.5 6 22 110 6 58 214.8
MC20 9 145 130 2.5 6 22 110 6 58 184.8
MB30 9 145 130 2.5 6 22 110 6 58 264.8
MC30 9 145 130 2.5 6 22 110 6 58 214.8
MH30 13.5 200 180 5 10 35 114.3 3.2 79 254
JSMA-PM
JSMA-PH
Series
Without
Brake
HH30 13.5 200 180 5 10 35 114.3 3.2 79 245
Unit: mm
