TEKNİM PARS SERIES INTRUDER ALARM SYSTEM INSTALLATION AND PROGRAMMING MANUAL
34 / 81
7.5 ZONE SETTINGS
This is the section where all settings related to zones are made.
7.5.1 Connection Type
The zone input must be set according to the connection type of the detector. The panel can be
adjusted according to the detector connections described in the installation section. Contact type
can be selected as NC (Normally Closed) or NO (Normally Open). Connection type can be selected
without resistance, single end resistance or double end resistance. Also unused zones can be turned
off in this section.
When double zone is activated for any zone from Zone 1 to Zone 8, the corresponding zone will be
activated. Which means if you activate double zone for Zone 1, the corresponding Zone 9 will be
activated. Below table, you can find the zone input settings;
Option
1.
2.
3.
4.
Feature
NC / NO
Single EOL Resistor
Double EOL Resistor
Zone Use / Not Use
LED ON
NC
Yes
Yes
In Use
LED OFF
NO
No
No
Not in Use
• LED Keypad;
Zone 1 - [20] [01] → [1-2-3-4] → [√ OK]
Zone 2 - [20] [02] → [1-2-3-4] → [√ OK]
Zone 3 - [20] [03] → [1-2-3-4] → [√ OK]
Zone 4 - [20] [04] → [1-2-3-4] → [√ OK]
Zone 5 - [20] [05] → [1-2-3-4] → [√ OK]
Zone 6 - [20] [06] → [1-2-3-4] → [√ OK]
Zone 7 - [20] [07] → [1-2-3-4] → [√ OK]
Zone 8 - [20] [08] → [1-2-3-4] → [√ OK]
• LCD Keypad;
[Zon Settings √ OK] → [Connection Type √ OK] → [1- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [2- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [3- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [4- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [5- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [6- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [7- Connection Type 1-2-3-4] → [√ OK]
[Zon Settings √ OK] → [Connection Type √ OK] → [8- Connection Type 1-2-3-4] → [√ OK]
PS 1: When a non-resistor connection is made, options 2 and 3 should be off.
PS 2: When zone doubling is made, both 2nd and 3rd options should be on.
PS 3: Zone doubling is not available on systems with additional zone cards.
Keypad Zone
Keypad zone connection is normally closed. If Keypad zone is to be used, this zone must be opened
in Connection Type settings.
