13. KEYPAD USAGE
This section describes the Keypad used for all functions of the alarm system and for panel
programming.
Teknim Pars serisies alarm systems supports totally 4 keypad connection. Information on how to
make the keypad connections can be found in section 6.5 Keypad Connection.
TSK-5718 LED KEYPAD
TSK-5710 LCD KEYPAD
Figure 24: TSK-5718 LED Keypad
Figure 25: TSK-5710 LCD Keypad
Status
Notification LED
Indicators
Status
Notification LED
Indicators
Partition and
Arrow Keys
Shortcut
Function Keys
Numeric Keys
and Ok-Cancel
Keys
2x16 LCD Screen
