LCD Keypad;
[Zone Settings √ OK] →[ Connection Type √ OK] → [1- Keypad Connection Type 1-4] → [√ OK]
[Zone Settings √ OK] →[ Connection Type √ OK] → [2- Keypad Connection Type 1-4] → [√ OK]
[Zone Settings √ OK] →[ Connection Type √ OK] → [3- Keypad Connection Type 1-4] → [√ OK]
[Zone Settings √ OK] →[ Connection Type √ OK] → [4- Keypad Connection Type 1-4] → [√ OK]
PS 1: Keypad zone can also be used on LED Keypad, but programming of Keypad Zone cannot be
done with LED Keypad.
PS 2: When the Keypad Zone is activated, double zone feature for this zone is not available.
However, double zone of other zones can be used.
The keypad zones uses 29-30-31-32 zone numbers in the system. Keypad address determines the
connected zone number.
If the Keypad address is 01 then Keypad Zone number is 29
If the Keypad address is 02 then Keypad Zone number is 30
If the Keypad address is 03 then Keypad Zone number is 31
If the Keypad address is 04 then Keypad Zone number is 32.
To learn Keypad adress see the section 7.10 Learn and Change the Keypad Adress.
!!! Important !!!
It is recommended that the detector to be connected to the keypad zone does not require a 12V
supply such as a magnetic contact. If the detectors using external supply are connected and the 12V
supply requirement is met via the Keypad, the Keypad cable distance may need to be significantly
reduced. Otherwise, instability may occur in the operation of the keypad.
7.5.2 Partition
In this section, you can set each zones to assigned related partition. Each zone can be assigned to
only one partition. But you can add multiple zones to a single partition.
1. Option: Partition A , 2. Option: Partition B, 3. Option: Partition C, 4. Option: Partition D
• LED Keypad;
Zone 1 - [21] [01] → [1-2-3-4] → [√ OK]
Zone 2 - [21] [02] → [1-2-3-4] → [√ OK]
Zone 3 - [21] [03] → [1-2-3-4] → [√ OK]
Zone 4 - [21] [04] → [1-2-3-4] → [√ OK]
Zone 5 - [21] [05] → [1-2-3-4] → [√ OK]
Zone 6 - [21] [06] → [1-2-3-4] → [√ OK]
Zone 7 - [21] [07] → [1-2-3-4] → [√ OK]
Zone 8 - [21] [08] → [1-2-3-4] → [√ OK]
• LCD Keypad;
[Zone Settings √ OK] → [Partition √ OK] → [1- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [2- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [3- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [4- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [5- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [6- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [7- Zone Partition A-B-C-D] → [√ OK]
[Zone Settings √ OK] → [Partition √ OK] → [8- Zone Partition A-B-C-D] → [√ OK]
