TEKNİM PARS SERIES INTRUDER ALARM SYSTEM INSTALLATION AND PROGRAMMING MANUAL
56 / 81
14 – TIMER SETTINGS
14 01
Timer 1 Settings
1. Option: Use PGM Timer YES/NO
2. Option: PGM Active / Passive
-
InP & MaP
14 02
Timer 1 Days
1. Option: Monday
2. Option: Tuesday
3. Option: Wednesday
4. Option: Thursday
5. Option: Friday
6. Option: Saturday
7. Option: Sunday
All Selected
InP & MaP
14 03
Timer 1 Time
HH: MM HH: Hour, MM: Minute
00:00
InP & MaP
14 04
Timer 2 Settings
1. Option: Use PGM Timer YES/NO
2. Option: PGM Active / Passive
-
InP & MaP
14 05
Timer 2 Days
1. Option: Monday
2. Option: Tuesday
3. Option: Wednesday
4. Option: Thursday
5. Option: Friday
6. Option: Saturday
7. Option: Sunday
All Selected
InP & MaP
14 06
Timer 2 Time
HH: MM HH: Hour, MM: Minute
00:00
InP & MaP
15 – REMOTE ACCESS
15 01
Remote Control Settings
1. Option: Remote Access by Phone ON/OFF
2. Option: Cloud Communication ON/OFF
OFF
OFF
InP
15 02
Ring Count
1~20 Times
5 Times
InP
16 – PANEL INFO
16 01
Panel Type
Only Read
TSP-5xxx
InP
16 02
Software Version
Only Read
0
InP
16 03
Hardware Version
Only Read
0
InP
2 – ZONE SETTINGS
20 – CONNECTION TYPE
20 01
20 02
20 03
20 04
20 05
20 06
20 07
20 08
Z1
Z2
Z3
Z4
Z5
Z6
Z7
Z8
01-Keypad Zone 29
02-Keypad Zone 30
03-Keypad Zone 31
04-Keypad Zone 32
1. Opt.: NC/NO
2. Opt.: Singl EOL, Double Zone On/Off*
3. Opt.: Double EOL, Double Zone On/Off*
4. Opt.: Zone Use In Use/Not In Use
 2 and 3 should be Off in Resistance-Free Connection.
 2 and 3 should be On in Double Zone Connection.
 Z9...Z(nx2) No Zone Activation Required.
 Double Zone is Not Available with Additional Zone Card.
Keypad Zone settings can only be done via LCD Keypad.
When the Keypad Zone is activated, the zone numbers
according to the Keypad address are assigned as follows;
Keypad 1: Zone 29
Keypad 2: Zone 30
Keypad 3: Zone 31
Keypad 4: Zone 32
1 – 4
1
InP
21 – PARTITION
21 01
21 02
21 03
21 04
21 05
21 06
21 07
21 08
Z1
Z2
Z3
Z4
Z5
Z6
Z7
Z8
01-Keypad Zone 29
02-Keypad Zone 30
03-Keypad Zone 31
04-Keypad Zone 32
1. Option: Partition A
2. Option: Partition B
3. Option: Partition C
4. Option: Partition D
A
InP
