TD-1/07-008
23 / 83
50 04
CMS Periodic Test Report
Range
1~48 hour
24 hours
65 IP
50 05
CMS Periodic Report Time
HH MM HH: Hour, MM:Minute
00:00
65 IP MP
50 06
Redialing Pause
1~30 sec.
3 sec.
65 IP
50 07
50 08
Communication Format
Central M. Station-1
Central M. Stat.ion-2
0=ContactID
1=4+2, 4+1, 3+2, 3+1 (DTMF)
0
65 IP
66
50 09
50 10
4+2, etc Features
Central M. Station-1
Central M. Stat.ion-2
(ON/ OFF)
1. option= Account No 3 Digit / 4 Digit
2. option= Code Digit 1 Digit / 2 Digit
3. option= Communication Frequency 20 Baud / 10 Baud
-
-
-
66 IP
50 11
50 12
50 13
50 14
50 15
Central M. Station to which
messages will be sent.
Out of Partition
A Partition
B Partition
C Partition
D Partition
1. option= Call Central Stat. 1
2. option= Call Central Stat. 2
S.P.T. uses settings of 50 11
1 = ON
67 IP
Look at pg.
34 for S.P.T
50 16
50 17
50 18
50 19
50 20
User Phones to which
messages will be sent.
Out of Partition
A Partition
B Partition
C Partition
D Partition
1.option= Call User number-1 S.P.T use s settings
2.option= Call User number-2 of 50 16
3.option= Call User number-3
4.option= Call User number-4
5.option= Call User number-5
6.option= Call User number-6
All options
are
selected
67 IP
Look at pg.
34 for S.P.T
ADDRESS
FUNCTION
VALUE
DEFAULT
VALUE
ENTERED
VALUE
PAGE &
PROGRAM
IP:Installer
MP:Master
