To change value :
LED 13 03 R √
LCD 1-PANEL SETTINGS → PGM SETTINGS → USE PGM 2 AS:
[ VALUE ] (Select using B(left) and C(right) buttons) √
R = Number between 0 and 10 (on Led Keypad)
Default Value : 0, Closed
Example : To use PGM2 as additional siren Output do “ 13 03 6 √ “
o PGM 2 Parameters
Address = 13 04 < IP >
To see value :
LED 13 04 (wait)
LCD 1-PANEL SETTINGS → PGM SETTINGS → PGM 2 SETTING (wait)
To change values :
LED 13 04 P..... P √
LCD 1-PANEL SETTINGS → PGM SETTINGS → PGM 2 SETTING
P P P √
PPP = Number between 0 and 255
Default Value : 0
Example :To configure parameter as 3 do “ 13 04 3 √ “
PGM 2 operates as siren when alarm is from first and second partition by above settings.
8.2.5. Timer Settings
PGM can be controlled by Timer1 or Timer2. PGM can be set to ON position in specific time of week or can
be set to OFF position in specific time of week. Before doing timer settings, PGM usage type has to be
selected as “9”(13 01 = 9). Timer settings can be done only for the first 4 PGM’s(PGM1 to PGM4). VAP404
PLUS has 2 PGM outputs. You can get 4 PGM outputs by using TRM904 module, or can get 8 PGM outputs
by using 2 TRM904 module together. Look at TRM904 guide for detailed description.
o To activate Timer1
Address = 14 01 < IP, MP >
To see value :
LED 14 01 (wait)
LCD 1-PANEL SETTINGS → TIMERS → TMR 1 SETTINGS (wait)
To see values :
LED 14 01 S ........S √
LCD 1-PANEL SETTINGS → TIMERS → TMR 1 SETTINGS
S ........S √
S = Multi choice selection(1,…, 8)
Default Value : All settings are closed
Example : To activate PGM1 in specific time do
14 01 1 (ON) 2 (ON) √
o Timer 1 Days
This setting provides selects on which day timer1 controls PGM1.Meaning of options is in the following.
1=Monday, 2=Tuesday, 3=Wednesday, 4=Thursday, 5=Friday, 6=Saturday, 7=Sunday
Address = 14 02 < IP, MP >
To see value :
