Type
Description
Parameter
Def.
Value
10
PGM random output ON/OFF
Param.
PGM ON Time
PGM OFF Time
0
1...255 second
1...255 second
1
1...255 minute
1...255 minute
2
1...63 second
1...255 second
3
1...63 minute
1...255 minute
0
11
PGM is activated on ARM
The working time between 0...255 as minute.
Note: If the number is 0, it works until closing by another source.
0
12
PGM is activated on DISARM
The working time between 0...255 as minute
Note: If the number is 0, it works until closing by another source.
0
13
PGM is activated on RC panic
button
The working time between 0...255 as minute.
Note: If the number is 0 and when the button is pushed the mode
changes.
0
14
PGM is activated on relevant
alarm occour
The table values of the
selected alarms are
added to each other
and entered.
Exp: For Intruder and Fire alarms 1+4=5 is entered.
Alarm
Value
Alarm
Value
Intruder
1
Duress
8
Panic
2
Tamper
16
Fire
4
Medical
32
63
(*)9. option is valid for the first four PGM’s(PGM1 to PGM4)
o PGM 1 Usage
Address = 13 01 < IP >
To see value :
LED 13 01 (wait)
LCD 1-PANEL SETTINGS → PGM SETTINGS → USE PGM 1 AS: (wait)
To change value :
LED 13 01 R √
LCD 1-PANEL SETTINGS → PGM SETTINGS → USE PGM 1 AS:
[ VALUE]
(Select using B(left) and C(right) buttons) √
R = Number between 0 and 10 (on LED Keypad)
Default value : 0, Closed
Example : To assign PGM1 to zones 13 01 1 √
o PGM 1 Parameters
Address = 13 02 < IP >
To see value :
LED 13 02 (wait)
LCD 1-PANEL SETTINGS → PGM SETTINGS → PGM 1 SETTING (wait)
To change value :
LED 13 02 R R R √
LCD 1-PANEL SETTINGS → PGM SETTINGS → PGM 1 SETTING
P P P √
PPP = Number between 0 and 255
Default Value : 0
Example : To configure parameter as 2 do “ 13 02 2 √ “
o PGM 2 Usage
Address = 13 03 < IP >
To see value :
LED 13 03 (wait)
LCD 1-PANEL SETTINGS → PGM SETTINGS → USE PGM 2 AS: (wait)
