LED 16 01 (wait)
LCD 1-PANEL SETTINGS → KEY SETTINGS → KEY A/D SETTING (wait)
To change values :
LED 16 01 S S √
LCD 1-PANEL SETTINGS → KEY SETTINGS → KEY A/D SETTING
S S √
S = Multi choice selection
Default Value : All options are closed.
Example : To activate key input in pulse mode do “ 16 01 1 (ON) 2 (OFF) √ “
o Key Partitions
Partitions that are selected here are armed by key input.
1. option=A partition, 2. Option=B partition, 3. Option=C partition, 4. Option=D partition
Address = 16 02 < IP >
To see value :
LED 16 02 (wait)
LCD 1-PANEL SETTINGS → KEY SETTINGS → KEY A/D SETTING (wait)
To change value :
LED 16 02 S ........S √
LCD 1-PANEL SETTINGS → KEY SETTINGS → KEY A/D SETTING
S ........S √
S = Multiple choice selection
Default Value : 1=A partition, 2=B partition, 3=C partition, 4=D partition
Example : To select only A partition for Key do
“ 16 02 1 (ON) 2 (OFF) 3 (OFF) 4 (OFF) √ “
8.3. ZONE SETTINGS
8.3.1. Zone Wiring
Each Zone can be programmed to use with NC, NO contacts and single EOL(End of Line) resistor, double
EOL resistor can be used in wiring or you don’t use EOL. You can close any zone that will not be used in the
same programming address. Meanings of options in installer address of 20 0X (X=Zone Number) are in the
following.
1. option 4. option
ON NC contact Zone ON
OFF NO contact Zone OFF
2. option 3.option
None EOL resistor OFF OFF
Single EOL resistor ON OFF
Double EOL resistor OFF ON
Zone Doubling ON ON (From Z1 to Z4)
Zone quantity can be increased to 8 by zone doubling feature. You make zone doubling by using
1kΩ and 2kΩ resistors connected to zone. Zone doubling is enabled in Zone Wiring section of Installer
Program. Each physical zone can be used as 2 zone by zone doubling. Contact types(NC,NO) of zones
can be configured from their addresses. Zone doubling feature can’t be used together with zone expander
module. Double zones are Z1-Z5, Z2-Z6, Z3-Z7, Z4-Z8.
Look at Zone Wiring section in 9.3.1 for details.
Note: Default Zone wiring is NC and None EOL resistor.
o Zone1 Wiring
Address = 20 01 . < IP >
