9.1.5. Meaning of lights
LIGHT
MAIN FUNCTION
SECONDARY
FUNCTION
TROUBLE
MEANING(Together with
trouble light)
1-8
Motion detect
Displays values in
programming mode
Look at Trouble Code
Power
AC Power detect
-
No AC Power
Program
Displays you are in
programming mode
-
Battery is in low level (with
Power led)
Bypass
There is bypassed zones in
Panel
“0”
Time, date trouble
Memory
Displays event log
“9”
No Telephone line
Ready
Panel is ready to Arm
-
-
Armed
Panel is Armed
-
-
Trouble
There is a trouble in Panel
-
-
Fire
Fire alarm
-
-
A, B, C, D
Motion detect on that
Partition
Display Partitions you
have selected
-
9.1.6. Keypad Addresses
Look at PROGRAMMING SETTINGS Section.
9.1.7. Keypad Inner Settings
Look at DETAILED PROGRAMMING Section.
9.1.8. Reports
Keypad displays kind of reports when you press following buttons.
6 (Report)(long) 1 Displays Armed zones and Partitions
6 (Report)(long) 2 Displays last zone and partition that alarms
6 (Report)(long) 3 Displays active PGMs
6 (Report)(long) 4 Displays Keypad address
6 (Report)(long) 5 Displays bypassed zones and partitions
6 (Report)(long) 6 Displays troubles
9.1.9. Troubles
A trouble will be indicated by trouble light that will remain ON until trouble condition is cleared. To view the
type of trouble, press 6 (Report)(long) 6. If Power light flashes with Trouble light, it indicates that AC Power
has lost. If Power and Program light flashes with Trouble light, it indicates low battery. If Bypass light
flashes with Trouble light, it indicates loss of time on system clock. If Memory light flashes, it indicates
telephone line trouble.
Type of Troubles is on the following table when zone leds lights with Trouble light.
TROUBLES
Zone lights
Reason
Type of Trouble
1
2
3
4
5
6
7
8
Invalid address

Invalid address has been entered.
Invalid data

Data that has been entered doesn’t like as
expected.
