Trouble Fire Type of Value
Off Off Number
Flashing Off Single Choice
Off Flashing Multiple Choice
User presses its number to select/unselect option.
Enter 4 digit address value to reach specific address.
Example: 01 02
If you enter wrong address, you will hear short beep and see that Trouble and 1.zone led flashing. To learn
meanings of Troubles, look at Trouble Codes Section.
To exit address, press X button.
When you enter address, you see value in that address and when keypad displays last digit of value in that
address, all zone leds flashes and start displaying value of address from the beginning.
To change values in address, enter new value and press √ button. If correct value is entered, you hear that
2
short beep otherwise you hear long beep and see trouble led flashing. To learn meanings of Troubles, look
at Trouble Codes Section.
9.1.3. Functions of Buttons
BUTTON
MAIN FUNCTION
SECONDARY FUNCTION
1
“1”
Panic
2
“2”
Fire
3
“3”
Duress
4
“4”
Program – To enter programming mode
5
“5”
Bypass
6
“6”
Report
7
“7”
Chime – Open/Close Chime function
8
“8”
Test
9
“9”
Memory –To display event log
0
“0”
Reset – To disarm fire alarm
X
Cancel
Exit
√
OK
Password – To change passwords
A
Selects A Partition or zones except
inner zones
Arms A Partition or zones except inner zones
B
Selects B Partition or Windows
Arms B Partition or Windows
C
Selects C Partition or Doors
Arms C Partition or Doors
D
Selects D Partition or all zones
Arms D Partition or all zones
NOTE: Secondary functions of buttons are activated by pressing button long.
9.1.4. Meanings of Beep Sounds
BEEP
MEANING
Long single beep
Trouble on last operation
Two short beep
Confirmation of operation
Periodic short
beep
Enter/Exit time
Periodic long beep
Alarm
