Note: (1) “(R) ” icon shows that restore code of event is automatically recorded and sent to CMS if it is selected in 51 XX.
(2) Special Arm/Disarm code is sent to Central Monitoring Station on Quick Arm, Arming on no activity, Automatic Arm/Disarm,
Arm/Disarm by key, Arm/Disarm by Remote Controller.
(3) Type of reset 1= Codes have been returned to factory defaults.
2= Panel Settings have been returned to factory defaults.
3= Both Panel Settings and Codes have been returned to factory defaults.
8.6.4. DTMF 4+2,etc Event Codes
These codes are sent to Central Monitoring Station. Use following table to enter or read hexadecimal data,
Example: To enter “ A3 “, press A(long) then press 3
While reading data, 0 and 1 (together) then 3 lights in VPC108 Keypad.
o Intruder Alarm Code
Address = 53 01 . < IP >
To see value :
LED 53 01 (wait)
LCD 5-COMMUNICATOR → 53-4+2 CODES → 01-INTRUDER ALM (wait)
To change value :
LED 53 01 RR √
LCD 5-COMMUNICATOR → 53 4+2 CODES → 01-INTRUDER ALM
RR √
RR = event code
Example : To set code as D1 do “ 53 01 4(long) 1 √ “
Note: If the second digit of event code is “0” , the following parameters in the table are sent to the CMS.
