Teknim VAP404 - Keypad Partitions; User Settings; Start Time

TD-1/07-008
57 / 83
Example : To disable 1. keypads quick arm permission do
“ 30 01 2(OFF) √ “
o Keypad 2 Permissions
Address = 30 02 < IP >
Default Value : 2=Quick Arm Enabled, 3= Arm Enabled, 4= Disarm Enabled
o Keypad 3 Permissions
Address = 30 03 < IP >
Default Value : 2=Quick Arm Enabled, 3=Arm Enabled, 4= Disarm Enabled
o Keypad 4 Permissions
Address = 30 04 < IP >
Default Value : 2=Quick Arm Enabled, 3=Arm Enabled, 4=Disarm Enabled
8.4.2. Keypad Partitions
Each keypad can be assigned to different partitions so can keypad controls partitions it is authorized. As a
default each keypad is assigned to all partitions.
Keypad Partition address is 31 0X (X= Keypad address).Following table shows options in that address.
1. option=A partition, 2. option=B partition, 3. option=C partition, 4. option=D partition
S.P.T. : 1.option= Interior, 2.option= Window, 3.option= Door, 4.option= Exterior
All partitions must be selected on S.P.T.(Look at page 34 for detailed description)
o Keypad 1 Partition
Address= 31 01 < IP >
To see value :
LED 31 01 (wait)
LCD 3-KEYPAD SETTING → PARTITIONS → 01-AUTHORISED (wait)
PARTITIONS:
To change value :
LED 31 01 S ........S √
LCD 3-KEYPAD SETTINGS →PARTITIONS → 01-AUTHORISED
S ........S √
S = Multiple choice selection
Default Value : 1=A partition, 2=B partition, 3=C partition, 4=D partition
Example : To assign 1.keypad to A and B partitions do
31 01 1(ON) 2(OFF) 3(OFF) 4(OFF) √
o Keypad 2 Partition
Address = 31 02 < IP >
Default Value : 1=A partition, 2=B partition, 3=C partition, 4=D partition
o Keypad 3 Partition
Address=31 03 < IP >
Default Value : 1=A partition, 2=B partition, 3=C partition, 4=D partition
o Keypad 4 Partition
Address=31 04 < IP >
Default Value : 1=A partition, 2=B partition, 3=C partition, 4=D partition
8.5. USER SETTINGS
Arm/Disarm permissions of users can be restricted. User’s Start/Finish Time(on selected Days), partitions,
Keypads can be configured. Installer, Master and Duress code permissions can’t be restricted.
8.5.1. Start Time
User can only start Arm/Disarm panel from beginning of start Time.
