Teknim VAP404 - Meaning of Beep Sounds; Meaning of Lights; Keypad Addresses; Keypad Inner Settings

TD-1/07-008
82 / 83
X
Cancel
Exit
√
OK
Password – To change password
A
Selects A Partition or zones except
inner zones
Arms A Partition or zones except inner zones
B
Selects B Partition or Windows
Arms B Partition or Windows
C
Selects C Partition or Doors
Arms C Partition or Doors
D
Selects D Partition or all zones
Arms D Partition or all zones
Also A,D,B,C buttons are used as arrow buttons while exploring menu.
9.2.4. Meaning of Beep Sounds
BEEP
MEANING
Long single beep
Trouble on last operation
Two short beep
Confirmation of operation
Periodic short
beep
Enter/Exit time
Periodic long beep
Alarm
9.2.5. Meanings and functions of lights
LIGHT
MAIN FUNCTION
SECONDARY FUNCTION
Ready
Panel is ready to Arm
-
Armed
Panel is Armed
-
Trouble
There is a trouble in Panel
-
Fire
Fire alarm
-
A, B, C, D
Motion detect on that Partition
Display Partitions you have selected.
9.2.6. Keypad Addresses
Look at Keypad Configurations Part in Programming Settings.
9.2.7. Keypad Inner Settings
Look at Keypad Configurations Part in Programming Settings.
9.2.8. Reports
Keypad displays kind of reports when you press following buttons.
6 (Report)(long) 1 Displays Armed zones and Partitions
6 (Report)(long) 2 Displays last zone and partition that alarms
6 (Report)(long) 4 Displays Keypad address
6 (Report)(long) 5 Displays bypassed zones and partitions
6 (Report)(long) 6 Displays troubles
9.2.9. Troubles
A trouble will be indicated by trouble light that will remain ON until trouble condition is cleared and type of
troubles is displayed on screen sequentially.
Type of troubles is on the following table.
TROUBLE MESSAGES
Reason
Invalid address
Invalid address has been entered
Invalid data
Data that has been entered doesn’t like as expected
No permission
Your permissions are limited
