To see value :
LED 20 01 (wait)
LCD 2-ZONE SETTINGS → CONNECTION TYPE → 01-CONNECT TYPE (wait)
To change value :
LED 20 01 S ........S √
LCD 2-ZONE SETTINGS → CONNECTION TYPE → 01-CONNECT TYPE
S ........S √
S = option(ON/OFF)
Default Value : 1. option = ON, 2. option= OFF 3. option = OFF, 4. option = ON
Example : To set 1.zone to NO contact do
20 01 1 (OFF) 2 (OFF) 3 (OFF) 4 (ON) √
: To set 1.zone to NC contact and double EOL resistor
do “ 20 01 1 (ON) 2 (OFF) 3 (ON) 4 (ON) √ “
o Zone2 Wiring
Address = 20 02 < IP >
Default Value : 1. option = ON, 2. option= OFF, 3. option = OFF, 4. option = ON
o Zon3 Wiring
Address= 20 03 < IP >
Default Value : 1. option = ON, 2. option= OFF 3. option = OFF, 4. option = ON
o Zone4 Wiring
Address = 20 04 < IP >
Default Value : 1. option = ON, 2. option= OFF 3. option = OFF, 4. option = ON
o Zone5 Zone8 Wiring
Address = 20 05-08 < IP >
Default Value : 1. option = ON, 2. option= OFF 3. option = OFF, 4. option = ON
8.3.2 Zone Partitions
Each zone can be assigned to one of the A, B, C, D Partitions. Meanings of options are in installer address
of 21 0X (X=Zone number).
1.option= A Partition, 2.option= B Partition, 3.option= C Partition, 4.option=D Partition
S.P.T doesn’t use this setting. Look at page 34 for detailed description.
o Defining Partition of Zone1
Address= 21 01 < IP >
To see value :
LED 21 01 (wait)
LCD 2-ZONE SETTINGS → PARTITION → 01-ZONE (wait)
PARTITION:
To change value :
LED 21 01 P √
LCD 2-ZONE SETTINGS → PARTITION → 01-ZONE
PARTITION: P √
P = Partition.(1=A Partition, 2=B Partition, 3=C Partition, 4=D Partition ; Single choice
Default Value : 1 = A Partition
Example : To assign Zone1 to C partition do “ 21 01 3 √ “
o Defining Partition of Zone2
Address = 21 02 < IP >
Default Value : 1 = A Partition
o Defining Partition of Zone3
Address = 21 03 < IP >
