LED 43 01 (wait)
LCD 4-USER SETTINGS → PARTITIONS → 01-AUTHORISED (wait)
To change value :
LED 43 01 S ........S √
LCD 4-USER SETTINGS → PARTITIONS → 01-AUTHORISED
S........S √
S = Multi choice selection(1, 2, 3, 4)
Default Value : 1=ON, 2=ON, 3=ON, 4=ON
Example : To select A, B partitions do
43 01 1 (ON) 2 (ON) 3 (OFF) 4 (OFF) √
o User-2 Partitions
Address = 43 02 < MP >
Default value : 1=ON, 2=ON, 3=ON, 4=ON
o User-3 Partitions
Address = 43 03 < MP >
Default Value : 1=ON, 2=ON, 3=ON, 4=ON
o User-4 Partitions
Address = 43 04 < MP >
Default Value : 1=ON, 2=ON, 3=ON, 4=ON
o User-5 Partitions
Address = 43 05 < MP >
Default Value : 1=ON, 2=ON, 3=ON, 4=ON
o Guest Partitions
Address = 43 06 < MP >
Default Value : 1=ON, 2=ON, 3=ON, 4=ON
8.5.5 User Keypads
User can only Arm/Disarm panel from his/her Keypads. Meaning of options is in the following;
1.option=1.keypad, 2.option =2.keypad, 3.option =3.keypad, 4. option = 4.keypad
o User-1 Keypads
Address = 44 01 < MP >
To see value :
LED 44 01 (wait)
LCD 4-USER SETTINGS → KEYPADS → 01-AUTHORISED (wait)
To change value :
LED 44 01 S ........S √
LCD 4-USER SETTINGS → KEYPADS → 01-AUTHORISED
S........S √
S = Multi choice selection (1, 2, 3, 4)
Default Value : 1 = ON, 2 = ON, 3 = ON, 4 = ON
Example : To assign 1.keypad and 2.keypad to User-1 do
“ 44 01 1 (ON) 2 (ON) 3 (OFF) 4 (OFF) √ “
o User-2 Keypads
Address = 44 02 < MP >
Default Value : 1 = ON, 2 = ON, 3 = ON, 4 = ON
o User-3 Keypads
Address = 44 03 < MP >
Default Value : 1 = ON, 2 = ON, 3 = ON, 4 = ON
o User-4 Keypads
Address = 44 04 < MP >
Default Value : 1 = ON, 2 = ON, 3 = ON, 4 = ON
