Teknim VAP404 - Zone Types

TD-1/07-008
54 / 83
Default Value : 1 = A Partition
o Defining Partition of Zone4
Address = 21 04 < IP >
Default Value : 1 = A Partition
o Defining Partition of Zone5  Zone8
Address = 21 05-08 < IP >
Default Value : 1 = A Partition
8.3.3 Zone Types
Zone types are selected in this address. One zone has only one type. Numbers of Zone types are in the
following.
Option
Zone Type
Description
0
Free zone
1
Door
Used with magnetic contacts that is connected doors. If Panel is
configured as Smart Partition, Panel automatically assigns that
zone to Door Partition
2
Window
Used with magnetic contacts that is connected windows. If
Panel is configured as Smart Partition, Panel automatically
assigns that zone to Window Partition.
3
Interior
Used with interior areas. If this zone is used as follower zone,
you should select follower zone option in address of 23 0X (X=
zone number).
4
Exterior
Used with detectors that is connected out of home.
5
24 Hour
This zone alarms if panel armed or disarmed when zone is
active.
6
Fire
This zone alarms if panel armed or disarmed when zone is
active. To silent alarm from this zone enter user code or press
[0(long)].
7
Panic
This zone alarms if panel armed or disarmed when zone is
active and communicator sends Panic alarm code to Central
Monitoring Station.
8
Duress
This zone alarms if panel armed or disarmed when zone is
active and communicator sends Duress alarm code to Central
Monitoring Station.
9
Tamper (Sabotage)
This zone alarms if panel armed or disarmed when zone is
active and communicator sends Tamper alarm code to Central
Monitoring Station .
10
Medical
This zone alarms if panel armed or disarmed when zone is
active and communicator sends Medical alarm code to Central
Monitoring Station
11
Custom Zone
This zone is always active. This zone can be customized
according to user’s request. For example; flood zone can be
determined to this zone.
o Type of Zone1
Address = 22 01 < IP >
To see value :
LED 22 01 (wait)
LCD 2-ZONE SETTINGS → ZONE TYPE → 01-ZONE TYPE (wait)
To change Value :
LED 22 01 R R √
LCD 2-ZONE SETTINGS → ZONE TYPE → 01-ZONE TYPE
R R √
R R = Zone type
Default Value :1 = Door
Example :To set 1. zone to Interior do “ 22 01 3 √ “
