Teknim VAP404 - Remote Controlling; Setting Zone as KEY Input

TD-1/07-008
51 / 83
Panel controls PGM2 in specified time of week.
Address = 14 06 . < IP, MP >
To see value :
LED 14 06 (wait)
To change value :
LED 14 06 HH MM √
LCD 1-PANEL SETTINGS → TIMERS → TMR 2 SETTINGS
HH MM √
HH = hours, MM = minutes
Default Value : 00:00
Example : To set time as 08:30 do “ 14 06 08 30 “ √
8.2.6. Remote Controlling
User can call controls some features of Panel remotely.
REMOTE CONTROL
Phone
PC Software (Modem) *
Enable / Disable
Address
1. option(15 01)
2. option(15 01)
Value
OFF
OFF
Answer Ring
Count
Address
15 02
Value
5 times
* This feature is only active if modem module is connected to VAP404 panel.
o Enable/Disable Remote Contro
Remote control is enabled/disabled here. In addition to this, If code is entered wrong 5 times, remote control
is disabled automatically by panel. To enable remote control again, enter its address select its option,
Address = 15 01 < IP, MP >
To see value :
LED 15 01 (wait)
LCD 1-PANEL SETTINGS → REMOTE ACCES → REMAC OPTIONS (wait)
To change value :
LED 15 01 S S √
LCD 1-PANEL SETTINGS → REMOTE ACCES → REMAC OPTIONS
S √
S = Multiple choice selection(1, 2)
Default Value : Disabled
Example : To enable phone remote control do “ 15 01 1 (ON) √ “
o Answer Ring Count
Address = 15 02 < IP, MP >
To see value :
LED 15 02 (wait)
LCD 1-PANEL SETTINGS → REMOTE ACCES → RING COUNT (wait)
To change value :
LED 15 02 R R √
LCD 1-PANEL SETTINGS → REMOTE ACCES → RING COUNT
R R √
RR = Answer time, (1 ~ 20)
Default setting : 5
Example : To set ring count to 10 do “ 15 02 10 √ “
8.2.7. KEY Input
o KEY Input
Key input option is in the following.
1. option = KEY Enable/Disable
2. option = OFF(Pulse Mode)/ ON(Continues Mode)
Address = 16 01 < IP >
To see values :
