LED 14 02 (wait)
LCD 1-PANEL SETTINGS → TIMERS→ TMR 1 SETTINGS (wait)
DAYS:
To change value :
LED 14 02 S .......S √
LCD 1-PANEL SETTINGS → TIMERS→ TMR 1 SETTINGS
DAYS: S ........S √
S = Multi choice selection(1, 2, 3, 4, 5, 6, 7)
Default Value : 1=ON, 2=ON, 3=ON, 4=ON, 5=ON, 6=ON, 7=ON
Example : To select days except Saturday and Sunday do
“ 14 02 1 (ON) 2 (ON) 3 (ON) 4 (ON) 5 (ON) 6 (OFF) 7 (OFF) √ “
o Time of Timer1
Panel controls PGM1 in specified time of week.
Address = 14 03 < IP, MP >
To see value :
LED 14 03 (wait)
LCD 1-PANEL SETTINGS → TIMERS → TMR1 SETTINGS (wait)
TIME:
To change value :
LED 14 03 HH MM √
LCD 1-PANEL SETTINGS → TIMERS → TMR 1 SETTINGS
TIME: HH MM √
HH = hour, MM = minute
Default Value : 00:00
Example : To set time as 17:45 do “ 14 03 17 45 √ “
o To activate Timer2
Address = 14 04 . < IP, MP >
To see value :
LED 14 04 (wait)
LCD 1-PANEL SETTINGS → TIMERS → TMR 2 SETTINGS (wait)
To see value :
LED 14 04 S ........S √
LCD 1-PANEL SETTINGS → TIMERS → TMR 2 SETTINGS
S ........S √
S = Multiple choice selection(1,…, 8)
Default Value : All settings are closed
Example : To set PGM1 to OFF position in specific time do
“ 14 04 1 (ON) 2 (OFF) √ “
o Timer 2 Days
This setting provides selects on which day Timer1 controls PGM1. Meaning of options is in the following.
1=Monday, 2=Tuesday, 3=Wednesday, 4=Thursday, 5=Friday, 6=Saturday, 7=Sunday
Address = 14 05 < IP, MP >
To see value :
LED 14 05 (wait)
LCD 1-PANEL SETTINGS → TIMERS → TMR 2 SETTINGS (wait)
To change value :
LED 14 05 S ........S √
LCD 1-PANEL SETTINGS → TIMERS → TMR 2 SETTINGS
DAYS: S ........S √
S = Multi choice selection(1, 2, 3, 4, 5, 6, 7)
Default Value : 1=ON, 2=ON, 3=ON, 4=ON, 5=ON, 6=ON, 7=ON
Example : To select days except Saturday and Sunday do
“ 14 05 1 (ON) 2 (ON) 3 (ON) 4 (ON) 5 (ON) 6 (OFF) 7 (OFF) √ “
Time of Timer2
