Teknim VAP404 - PGM Output Settings

TD-1/07-008
47 / 83
Address= 12 08 < IP >
To see value :
LED 12 08 (wait)
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → INAC ARM DELAY (wait)
To change value :
LED 12 08 R R R √
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → INAC ARM DELAY
R R R √
R R R = 3 digit time( 5 ~ 255 in minutes)
Default Value : 30 minutes
Example : To set time to 60 minutes do 12 08 60 √
8.2.4. PGM Output Settings
This setting includes PGM usage. PGM has two addresses. One of them is for usage type, other is for
parameter address. VAP404 PLUS has 2 PGM outputs. You can get 4 PGM outputs by using TRM904
module, or can get 8 PGM outputs by using 2 TRM904 module together. Look at TRM904 guide for detailed
description.
Type
Description
Parameter
Def.
Value
0
Free PGM
Any value is not entered.
-
1
PGM becomes active while
selected zones are active
The table values of the
selected zones are added to
each other and entered.
Exp: For Z3 and Z6 zones,
4+32=36 is entered.
Zone
Value
Zone
Value
Z1
1
Z5
16
Z2
2
Z6
32
Z3
4
Z7
64
Z4
8
Z8
128
255
2
PGM becomes active while
selected partitions are active
The table values of the selected partition(s) are
added to each other and entered.
Exp: For B and C partitions, 2+4=6 is entered
Part.
Value
A
1
B
2
C
4
D
8
15
3
PGM is activated when selected
partitions are armed
The table values of the selected partition(s) are
added to each other and entered.
Exp: For B partition, 2 is entered
Part.
Value
A
1
B
2
C
4
D
8
15
4
PGM is activated on fire.(Fire
siren can be connected)
Any value is not entered. When the fire alarm is dedected, PGM
continuously activates.
-
5
Power of fire detector is
connected to PGM.
The resetting time of the detector between 1...255 as second.
10
6
PGM is connected to additional
siren that is related with
selected partitions
The table values of the selected partition(s) are
added to each other and entered.
Exp: For A and D partitions, 1+8=9 is entered
Part.
Value
A
1
B
2
C
4
D
8
15
7
PGM is activated while selected
troubles occur
The table values of the
selected troubles are
added to each other
and entered.
Exp: For Battery Low
and Zone Trouble,
2+16=18 is entered.
Trouble
Value
Trouble.
Value
AC Fail
1
Tel.Line
Fail
8
Battery
Low
2
Zone
Trouble
16
Time
Loss
4
Battery
Fail
32
63
8
PGM controls magnetic lock
connected to door
The keeping open time of the magnetic lock between 1...255 as
second.
5
9
PGM is activated/deactivated in
time specified in Timer1 or
Timer2 (*)
The working time between 0...255 as minute.
Note: If the number is 0, it works until closing by another source.
0
