8.7.2. Zone Expansion Module
Installer can enable or disable Zone module. Meaning of option is in the following table.
1. option
Zone Module
ON = Enabled
OFF = Disabled
Address = 61 01 < IP >
To see value :
LED 61 01 (wait)
LCD 6-MODULES → EXP ZONE SETTING → 01-EXP ZONE SETTING (wait)
To change values :
LED 61 01 S ........S √
LCD 6-MODULES → EXP ZONE SETTING → 01-EXP ZONE SETTING
S √
S = ON/OFF
Default Value : OFF
Example : To enable Zone Module do
“ 61 01 1 (ON) √ “
8.8. KEYPAD INNER SETTINGS
These settings are recorded to Keypad Memory. Do these settings on which keypads inner settings you want
to change. Addresses of Inner Settings are different in LED and LCD keypads.
8.8.1 VPC108 Led Keypad Inner Settings
o Open Chime
Chime activates when selected zone is opened.
1. Option=1. Zone, 2. Option=2. Zone, 3. Option=3. Zone, 4. Option=4. Zone
5. Option=5. Zone, 6. Option=6. Zone, 7. Option=7. Zone, 8. Option=8. Zone
Address = 99 01 < IP, MP >
To see value : LED 99 01 (wait)
To change value : LED 99 01 S........S √
S = Multiple choice selection
Default Value : All chimes are closed.
Example : If you want chime when zone1 and zone 3 are opened, do
“ 99 01 1(ON) 3(ON) √ “
o Close Chime
Chime activates when selected zone is closed.
1. Option=1. Zone, 2. Option=2. Zone, 3. Option=3. Zone, 4. Option=4. Zone
5. Option=5. Zone, 6. Option=6. Zone, 7. Option=7. Zone, 8. Option=8. Zone
Address = 99 02 < IP, MP >
To see value : LED 99 02 (wait)
To change value : LED 99 02 S ........S √
S = Multiple choice selection
Default Value : All chimes are closed.
Example : If you want chime when zone 1 and zone 4 are closed do
“ 99 02 1(ON) 4(ON) √ “
