LCD 5-COMMUNICATOR → 52-CONTACT ID CODES → 01-INTRUDER ALM (wait)
To change value :
LED 52 01 RRRR √
LCD 5-COMMUNICATOR → 52- CONTACT ID CODES → 01-INTRUDER ALM
RRRR √
RRRR = 4 digit event code
Default Value = 1130
Example : To set code as default value do “ 52 01 1130 √ “
List of event codes is in the following table
No
Event
Address
Menu
5-COMMNUNICATOR →
CONTACT ID CODES →
Event Codes
(Default Value)
Parameter
Prg
1
Intruder Alarm (R) (1)
52 01
01-INTRUDER ALARM
1130
Zone
IP
2
Panic Alarm (R)
52 02
02-PANIC ALARM
1120
Zone
IP
3
Fire Alarm (R)
52 03
03-FIRE ALARM
1110
Zone
IP
4
Duress Alarm (R)
52 04
04-DURESS ALARM
1120
Zone
IP
5
Sabotage-Tamper Alarm (R)
52 05
05-TAMPER ALARM
1144
Zone
IP
6
Medical Alarm (R)
52 06
06-MEDICAL ALRM
1100
Zone
IP
7
Disarm by Duress
52 07
07-DURESS DISARM
1121
-
IP
8
Disarm on Alarm
52 08
08- DISARM ON ALARM
1406
-
IP
9
Zone Trouble
52 09
09-ZONE TROUBLE
1372
Zone
IP
10
AC Fail (R)
52 10
10-MAINS FAILED
1301
-
IP
11
Intrusion Verifier
52 11
11-INTR. VERIFY
1139
-
IP
12
Cross Zone Fault
52 12
12- CROSS FAULT
1378
-
IP
13
Battery Low (R)
52 13
13-LOW BATTERY
1302
-
IP
14
Line Fail (R)
52 14
14-LINE FAIL
1351
-
IP
15
Battery Fail (R)
52 15
15- BATTRY FAIL
1302
-
IP
16
Communication Fail
52 16
16-COM FAIL
It is not sent to
CMS
-
IP
17
Special Arm/Disarm (R) (2)
52 17
17- SPECIAL ARM/
SPECIAL DISARM
1400
Parameter
IP
18
Arm/Disarm (R)
52 18
18-ARMED/
DISARMED
1402
User
IP
19
Bypassed (R)
52 19
19-BYPASSED/
BYPASS CANCEL
1570
Zone
IP
20
Entering Program
52 20
20-PROG BEGIN
1627
User
IP
21
Exiting Program
52 21
21-PROG END
1628
-
IP
22
Periodic Report
52 22
22-PER. REPORT
1602
-
IP
23
Panel Restarted
52 23
23-PANEL RESTART
1305
-
IP
24
Manual Report
52 24
24-MANUAL TEST
1601
-
IP
25
---
52 25
25-RESERVED
-
-
IP
26
---
52 26
26-RESERVED
-
-
IP
27
----
52 27
27-RESERVED
-
-
IP
