LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO ARM
PARTITIONS: S ........S √
S = Multiple choice selection
Default Value : All partitions are unselected
Example : To select all partitions for automatic arm do
“ 12 01 1(ON) 2 (ON) 3 (ON) 4 (ON) √ “
o Automatic Arm Days
Selected partitions are armed on time of selected days.
1=Monday, 2=Tuesday, 3=Wednesday, 4=Thursday, 5= Friday, 6=Saturday, 7=Sunday
Address=12 02 < IP, MP >
To see value :
LED 12 02 (wait)
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO ARM (wait)
DAYS:
To change value :
LED 12 02 S ........S √
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO ARM
DAYS: S ........S √
S =Multiple choice selection(1, 2, 3, 4, 5, 6, 7)
Default Value : 1=ON, 2= ON, 3= ON, 4= ON, 5= ON, 6 = ON, 7=ON
Example : To select days except Saturday and Sunday do
“ 12 02 1 (ON) 2 (ON) 3 (ON) 4 (ON) 5 (ON) √ “
o Automatic Arm Time
Selected Partitions are armed in specific time on selected days.
Address = 12 03 < IP, MP >
To see value :
LED 12 03 (wait)
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO ARM (wait)
TIME:
To change value :
LED 12 03 HH MM √
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO ARM
TIME: HH MM √
HH = hour, MM = minute
Default value : 00:00
Example : To set arm time to 17:45 do “ 12 03 17 45 √ “
o Automatic Disarm Partitions
Selected partitions in this address are automatically armed. To disable automatic arm feature, unselect
partitions. Meanings of options are in the following.
1. option = A partitions, 2. option=B partitions, 3. options=C partition, 4. options=D partition
S.P.T. : 1.option= Interior, 2.option= Window, 3.option= Door, 4.option= Exterior
It is recommended to select all partitions on S.P.T.(Look at page 34 for detailed description)
Address = 12 04 < IP >
To see value :
LED 12 04 (wait)
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO DISARM (wait)
PARTITIONS:
T o change value :
LED 12 04 S ........S √
LCD 1-PANEL SETTINGS → AUTO ARM/DISARM → AUTO DISARM
PARTITIONS: S ........S √
S = Multiple choice selection
Default Value : All disarm partitions are closed.
