1. option
Call Central
Station
3. option
Call User Phone
8. option
Record to Memory
ON
ON
ON
OFF
OFF
OFF
1.option
Call Central Station
2.option
Call User Phone
3.option
Send Restore Info
to CMS
4.option
Send Restore Info
to Phone
5.option
Record to Memory
ON
Yes
Yes
Yes
Yes
Yes
OFF
No
No
No
No
No
Keypad displays event logs in following order.
EE DD HH MM A B
EE : Event Code
DD : Day of event
HH MM: Time of event
A, B : Parameters
User parameters are recorded to memory as following;
0 = Installer 1= Master 2 = User-1 3 = User-2 4 = User-3 5 = User-4
6 = User-5 7 = Guest
o Intruder Alarm
Address = 51 01 < IP >
To see value :
LED 51 01 (wait)
LCD 5-COMMUNCATOR → REPORT MASKS → 01-INTRUDER ALARM (wait)
To change value :
LED 51 01 S ........S √
LCD 5-COMMUNICATOR → REPORT MASKS→ 01-INTRUDER ALARM S ........S √
S = Multiple choice selection
Default Value : 1=ON, 2=ON, 3=ON, 5=ON
Example : To disable dialing Central M. Station do
“ 51 01 1 (OFF) √ “
Event List is in the following table
No
Event
Address
Menu
5-COMMUNICATOR →
REPORT MASKS →
Options
Parameter
Prg
1
Intruder Alarm
51 01
01-INTRUDER ALARM
1, 2, 3, 5
A= - , B=Zone
IP
2
Panic Alarm
51 02
02-PANIC ALARM
1, 2, 3, 5
A=Keypad , B=Zone
IP
3
Fire Alarm
51 03
03-FIRE ALARM
1, 2, 3, 5
A=Keypad , B=Zone
IP
4
Duress Alarm
51 04
04-DURESS ALARM
1, 2, 3, 5
A=Keypad- , B=Zone
IP
5
Sabotage-Tamper Alarm
51 05
05-TAMPER ALARM
1, 2, 3, 5
A=Keypad , B=Zone
IP
6
Medical Alarm
51 06
06-MEDICAL ALRM
1, 2, 3, 5
A= - , B=Zone
IP
7
Disarm by Duress
51 07
07-DURESS DISARM
1, 2, 5
A= - , B= -
IP
