Replaceable Electrical Parts - 2230 Service
Tektronix
S eria l/A sssn bly No.
H fr.
Canponent No. Part No.
E ffe c tiv e
Dscont Name & D escription
Cods
M fr. P a rt No.
A21C10U
290-0246-00
CAP, FXD, ELCTLT: 3 .3UF, 10%,15V
12954
D3R3EA15K1
A21C1012
290-0246-00
CAP,FXD,ELCTLT:3 .3UF,10%,15V 12954
D3R3EA15K1
A21C1013
290-0246-00
CAP, FXD, ELCTLT:3 .3UF,10%,15V
12954 D3R3EA15K1
A21C1014
290-0246-00
CAP, FXD,ELCTLT:3.3UF,10%,15V
12954
D3R3EA15K1
A21C1015
290-0246-00
B010100
B021935
CAP,FXD,ELCTLT;3 .3UF,10%,15V
12954
D3R3EA15K1
A21C1221
281-0775-00
CAP.FXD.CER D I:0 .1UF,20%,50V
04222 MA205E104MAA
A21C1222
281-0775-00
CAP.FXD.CER 01:0.1UF,20%,50V
04222
KA205E104MAA
A21C1223
281-0775-00
CAP.FXD.CER D l:0 .IUF.20%,50V
04222 MA205E104MAA
A21C1224
281-0775-00
CAP.FXD.CER D1:0.IUF.20%.50V
04222
MA205E104MAA
A21C1225
283-0197-00
CAP.FXD.CER D I:470PF,5%.E.0V 04222
SR205A471JAA
A21C1226
283-0197-00 CAP.FXD.CER DI:470PF,5%,50V
04222 SR205A471JAA
A21C1227
283-0197-00
CAP.FXD.CER 0I:470PF,5°/.,E*0V
04222
SR205A471JAA
A21C1228
283-0197-00
CAP.FXD.CER D I:470PF,5%.50V
04222 SR205A471JAA
A21C1229
283-0197-00
CAP.FXD.CER D I:470PF,5%,50V
04222 SR2054471JAA
A21C1232
281-0773-00
CAP.FXD.CER DI:0.01UF, 10X.100V
04222
MA201CI03XAA
A21C1233
281-0773-00
CAP.FXD.CER D I:0.01UF,10%,I00V 04222 M4201C103K4A
A21C1234
281-0775-00
CAP.FXD.CER D I:0 .1UF,20%,50V 04222 M4205E104MAA
A21C1235 281-0775-00
CAP.FXD.CER 01 -.0.IUF.20%.:50V
04222
MA205E104MAA
A21C123S 283-0197-00
CAP.FXD.CER DI:470PF,5%,50V
04222 SR205A471JAA
A21C1237
281-0775-00
CAP.FXD.CER DI :0.1UF,20%.50V 04222
MA205E104MAA
A21C1238
283-0197-00
CAP.FXD.CER DI:470PF,5%,50V
04222
SR205A471JAA
A21C1239
283-0197-00
CAP.FXD.CER D I: 470PF,5%.50V
04222
SR205A471JAA
A21C1240 281-0775-00
CAP.FXD.CER DI:0.IUF,20%,50V
04222
MA205E104MAA
A21C1242
281-0773-00
CAP.FXD.CER D I: 0-01UF,10%,100V 04222 KA201C103KAA
A21C1243 281-0773-00
CAP.FXD.CER D I:0.01UF,10%,100V 04222 MA201C103KAA
A21C1244 281-0773-00
CAP.FXD.CER 01 :0 .01UF,10%.100V 04222 KA201C103KAA
A23C1251 281-0773-00
CAP.FXD.CER D I:0.01 UF, 10%. 100V
04222 MA201C103KAA
A21C1252
283-0639-00
CAP,FXD,MICA DI:56PF,1%,1Q3V
00853
D155E560F0
A21C1253 283-0539-00 CAP,FXD,MICA Dl:56PF,1%,100V 00853
D155E560F0
A21CR1001 152-0141-02
SEMICO® DVC.DI:SW,SI,30V,150MA,30V,DO-35
03508
DA2527 (1N4152)
A21CR1002 152-0141-02 SEMICOND DVC,D I:SW,S1,30V,1 SOMA,30V,DO-35
03508 DA2527 (1N4152)
A21CR1003 152-0141-02
SEMICO® DVC,DI-.SW,SI,30V,150MA,30V,DO-35
03508 DA2527 (1N4152)
A21CR1011 152-0141-02
SEMICOND DVC,D I:SW,S1,30V.150M4,30V,DO-35
03508 DA2527 (1N4152)
A21CR1012
152-0141-02
SEMICOND DVC,DI:SW,SI,30V,150MA,30V,DO-35 03508 DA2527 ( 1N4152)
A21CR1014 152-0141-02
SEMICOND DVC,D I: SW,S !,30V,150MA,30V, DO-35 03508 DA2527 ( 1N4152)
A21CR1016
152-0141-02
SEMICOND DVC,DI:SW,SI,30V,150M4.30V,DO-35 03508
DA2527 (1N4152)
A21CR1221
152-0834-01 SEMICOND DVC.DI:16 DIODE ARRAY,COMMON ANODE 80009
152-0834-01
A21CR1222 152-0835-01
SEMICOND DVC.DI:16 DIODE WRAY.COM CATHODE 80009 152-0835-01
A21CR1223 152-0141-02
SEMICOND DVC, D I:SW,S1,30V,1 50MA,30V,DO-35 03508 DA2527 (1N4152)
A21CR1224
152-0141-02
SEMICOND DVC.DI :SW,SI,30V,1.30M4.30V,DO-35
03508
DA2527 (1N4152)
A21E1011
315-0681-00
RES,FX0,FIIM:680 0rM,5%,0.25W
57668
NTR25J-E680E
A21F1001
159-0090-00 FUSE,WIRE LEAD:0 .25A.125V,0 .085SEC TK0946
SP1-0.25 A
A21J1011
131-3390-00 CONN,RCPT,ELEC:D SUBMIN.CICT BD,9 CONTACT
13556
DE-9SV
A21J1212
131-0813-00
CONN,RCPT,ELEC:CKT BD MT.25 CONT.MALE 13511 777-D3-25P-T
A21J1214
131-0971-00
CONN.RCPT,ELEC:CKT BD MT.25 CONTACT.FEMALE
71468 DB25-SH
A21J1216
131-0589-00 TERM,INAL,PIN:0.45 L X 0.025 SQ PH BRZ
22526
48283-029
A21J1217
131-0589-00
TERMINAL,PIN:0.46 L X 0.025 SQ PH BRZ
22526
48283-029
A21J1222
131-0589-00
TERMINAL,PIN:0.46 L X 0.025 SQ PH BRZ
(QUANTITY OF 20)
22526 48283-029
A21J1231
131-0589-00 TERMINAL,PIN:0.46 L X 0.025 SQ PH BRZ
22526 48283-029
A21J1242
131-0589-00
TERMINAL,PIN:0.46 L X 0.025 SQ PH BRZ
22 526 48283-029
A21J1251
131-0589-00
TERMINAL,P1N:0.46 L X 0.025 SQ PH BRZ
(QUANTITY OF 20)
22526
48283-029
A21J4110
131-0589-00 TERMINAL.PIN:0.45 L X 0.025 SQ PH BRZ
(QUANTITY OF 2)
22526 48283-029
A21J6423
131-0589-00 TERMINAL,PIN.-0.46 L X 0.025 SQ PH BRZ
(QUANTITY OF 4)
22526
48283-029
A21J9301 131-0589-00
TERMINAL,P1N:0.46 L X 0.025 SQ PH BRZ
22526 48283-029
