Analyze Wavefor
mData
2. With cursors on, push Select.
This turns the cursor linking on and off. If
linking is on,
turning multipurpose knob a
moves the two cursors together. Turning
multipurpose knob b adjusts the time
between the c
ursors.
3. Push Fine to toggle between a coarse and
a fine adjustment for multipurpose knobs a
and b.
Pushing Fine also changes the sensitivity of
other k nobs as well.
4. Push and hold Cursors to display the cursor
menu.
5. Push Curs
ors on the lower menu to set the
cursors to Screen.
In screen mode, two horizontal bars and two
vertica
l bars span the graticule.
Cursors
Waveform
Screen
Source
Auto
Bars
Horizont
al
Vertical
Linked
On|
Off
Bring
Cursors
On Screen
Cursor
Units
6. Turn multipurpose knobs a and b to move
the pair of horizontal cursors.
7. Push Select.
This
makes the horizontal cursors active
and the vertical ones inactive. Now, as you
turn the multipurpose knobs, the horizontal
cur
sors will move.
Push Select again to m ake the vertical
cursors active again.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 109
