Application Exa
mples
2. Push Type.
Type
3. Turn multipurpose knob a to scroll through
the trigger
type side menu until you select
Video.
Video
4. Push Video
Standard, and turn
multipurpose knob a to scroll through the
standards until you select 525/NTSC.
Type
Video
Video
Standard
525/NTSC
Source
1
Trigger On
All Lines
Mode
Auto
& Holdoff
5. Push Trigger On.
6. Select Odd Fields.
Odd Fiel
ds
If the signal had been noninterlaced, you
could c
hoose to trigger on All Fields.
7. Turn the Horizontal Scale knob to see a
compl
ete field across the screen.
8. View results.
152 MSO3000 and DP O3000 Series Oscilloscopes User Manual
