Installation
3. Push Utility.
4. Push Utility Page.
Utility
Page
5. Turn multi
purpose knob a and select I/O.
I/O
6. If you are using U SB, the system sets itself
up automa
tically for you, if USB is enabled.
Utility
Page
I/O
USB
Computer
Ethernet
Network
Settings
Socket
Server
GPIB
1
Check USB on the l ower menu to be sure
that USB
is enabled. If it is not enabled, push
USB. Then push Connect to Computer on
the side menu.
Change
Instru
ment
Settings
DHCP/
BOOTP
On|O
ff
7. To use E
thernet, push Ethernet Network
Settings.
On the side menu, if you are on a DHCP
Ethern
et network and using a through
cable, set DHCP to On. If you are using a
cross-over cable, set it to Off and set a hard
coded
TCPIP address.
Test C
on-
nection
8. If yo
u want to change socket server
parameters, push Socket Server and enter
new values through the resulting side menu.
9. If you a re using GPIB, push GPIB . Enter
the GPIB address on the side menu, using
mul
tipurpose knob a.
Talk/Listen
Add
ress
(a) 1
This will set the GPIB address on an
at
tached TEK-USB-488 Adapter.
