Tektronix MSO4000B Series User Manual

Analyze Wavefor
mData
4. Push the top bu
tton on the side menu to
select the waveform axis for which you want
to show the histogram values: Vertical or
Horizontal.
Off
Vertical
Horizontal
5. Push Source on the side menu and use
multipurpos
e knob a to select the channel for
which to display histogram measurements.
Source
(a) 1
6. Push Horiz. Limits on the side menu and
use the mult
ipurpose knobs a and b to set
the L (left) and R (right) boundaries of the
histogram box.
Horiz.
Limits
L(a)
-584ns
R(b)
760ns
7. Push Vert. Limits on the side menu and
use the mul
tipurpose knobs a and b to set
the T (top) and B (bottom) boundaries of the
histogram box.
Vert.
Limits
T(a)
-584ns
B(b)
760ns
8. Push -more
-1of2.
-more-
1of2
9. Push Display on the side menu and select
Linear or
Log.
Display
Linear
Log
To Add Me
asurements on Histogram Data
1. Push Add Measurement on the lower menu
to add measurements on the histogram data.
Add Mea-
surement
Remove
Measure-
ment
Indicators Wave-
form His-
tograms
More
Bring
Cursors
On Screen
2. Push Source on the side m enu and turn
multipurpose knob a to select H for histogram
measurements.
Source
(a) H
3. Push Measurement Type onthesidemenu
and turn multipurpose knob b to select a
histogram measurement.
Measure-
ment
Type
(b) Peak
Hits
118 MSO4000B and DPO4000B Series O scilloscopes User Manual
