MyScope setups Set up a MyScope control window

Set up a MyScope control window

From the MyScope menu, select New Control Window.

Overview

MyScope allows you to create custom control windows that include only the controls you use regularly.

Instead of switching between several control windows, put the controls you use into a custom control

window.

To use

Click + to expand a control category.

Click a control to preview it in the pane at the right.

Click the + additionally to expand the control list. (If there is no +, then the control cannot be

customized further.)

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 379
