Utilities User Preferences: Keypad Defaults

To use

Click a button to enable or disable the control setting.

Behavior

The conﬁ

rmation messages give users the chance to change their minds before taking action. The messages

generally explain the implications of the action.

All pre

ference settings are saved when you power off the instrument.

What do you want to do next?

Learn about setting user preferences for trigger level presets. (see page 556)

User Preferences: Keypad Defaults

From the Utilities menu, select User Preferences; then open the Keypad Defaults tab.

Overview

Use the Keypad Defaults tab to deﬁ ne the preset trigger levels.

556 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
