Howto? SetupanEthernetserialbus
Set up an Ethernet serial bus
First, follow the common steps to set up any bus (see page 580). To c ontinue to set up an Ethernet serial
bus, follow these steps:
1. To define the bus type in the Bus Setup window, click Serial as the Bus Type, and select Ethernet
from the drop-down list.
2. To select the s tandard, click Standard, and select the standard from the drop-down list.
3. To set a Signal Type, click Signal Type and select the signal type from the drop-down list.
4. To select the input for the displayed components of the bus, click on the component Input and select a
channel from the cascading list.
5. To set a threshold, double-click the Threshold entry boxes and use the keypad to enter the level.
6. Click the Display tab, and configure the bus display
(see page 590).
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 589
