Trigger setups Set up trigger controls (B Event tab)
Return to the Trigger Setup control window. (see page 385)
Trigger on nth Event (Horizontal Delay Off). (see page 453)
Trigger on nth Event (Horizontal Delay On). (see page 452)
Trigger on nth Event (B-Event Scan). (see page 455)
Set up trigger controls (B Event tab)
From the Trig menu, select B Event (Delayed) Trigger Setup.
To use
Use the co
ntrols is this window to define the parameters for the B Event trigger.
For information on the controls, click the buttons.
NOTE. On
MSO/DPO5000 Series instruments, trigger on B events is available only for Edge trigger.
Behavior
These controls work together to define the parameters for the trigger event. Use the B Event trigger with
the A Event trigger to capture more complex events. The B Event trigger controls are independent from
the A Event trigger. When you click on the trigger window c ontrols, the trigger graphic
(see page 386)
s
hows the trigger sequence.
What do you want to do next?
Learn about sequential triggering. (see page 909)
Learn about the A Event trigger types. (see page 386)
Learn a bout Trigger Mode and Holdoff. (see page 474)
