Oscilloscope R eference Video trigger autoset

Video trigger autoset

Autoset automatically sets the video trigger controls for the selected format and optimizes the vertical

sensitivity and time per division for viewing video lines and ﬁ elds. These controls do not appear if you

select the Cu

stom format.

Click Lines or Fields to optimize the settings.

Select the video trigger format

Select one of the predeﬁned video signal formats from the drop-down list:

525i/NTSC

625i/PAL

SECAM

Bilevel

Trilevel

1080i/60

1080i/50

480p/60

576p/50

720p

/30

720p/50

720p/60

875i/60

1080/24sF

1080p/24

080p/25

1080p/30

1080p/50

1080p/60

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 959
