GPS7 GPS Synchronization and Timecode module
GPO Signal Warn
ing. Use this feature to set a delay between the time when a
signal warning is detected and when it is reported on the GPI output. Press the
ENTER button, and then use the left (◄)orright(►) arrow button to select a
digit in the delay time before a GPO signal warning message is displayed. An
underline character appears under the selected digit. The d ate and time digits
take the following form: HH:MM:SS.
After you select a d igit, use the up (▲)ordown(▼) arrow button to change
the value of the digit. Repeat for each digit as required. Press the ENTER to
confirm the
change.
Black 2 B lank on Unlock. Usethisfeaturetosetadelaybetweenthetimewhenan
unlock is detected and when Black 2 is blanked. Press the ENTER button, and
then use the left (◄)orright(►) arrow button to select a digit in the delay time
before the BLACK 2 output is blanked for a loss of GPS/GLONASS signal lock.
An under
line character appears under the selected digit. The date and time digits
take the following form: HH:MM:SS.
After y
ou select a digit, use the up (▲)ordown(▼) arrow button to change
the value of the digit. Repeat for each digit as required. Press the ENTER to
confirm the change.
NOTE. The BLACK 2 output must be configured to be blanked before this delay
will be used. (See page 3-122, GPS7 module BLACK submenu.)
TG8000 Multiformat Test Signal Generator User Manual 3–147
