Tektronix TG8000 User Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module
30 DROP. Use thi
s menu selection to enable or disable the Drop Frame mode for
the 30 frame per second timecode format. Use the left (◄)andright(►) arrow
buttons to select Enable 30 Drop Frame or Disable 30 Drop Frame,andthen
press the ENTER buttontoconfirm the selection. This menu selection is a vailable
only when the frame or field rate for the current format is 29.97, 30, 59.94, or 60.
ATC-LTC. Us
e this menu selection to enable or disable the Ancillary Linear Time
Code. Use the left (◄)andright(►) arrow buttons to select Enable or Disable,
andthenpresstheENTER button to confirm the selection.
NOTE. If a GPS7 module is installed, the embedded LTC and VITC timecode
(when enabled) on the SDI7 module outputs also includes the SMPTE309 date,
time-zone offset, and DST enabled/disabled fields. The content of these fields
depends
on the SMPTE309 mode setting on the GPS7 module (Ignore, Use As
Input, or Use As Input/Output). (See page 3-133, GPS7 module TIME OF DAY
submenu.)
ATC-VI
TC. Use this menu selection to enable or disable the Ancillary Vertical
Interval Time Code. Use the left (◄) and right (►) arrow buttons to select
Enable or Disable, and then press the ENTER buttontoconfirm the selection.
3–322 TG8000 Multiformat Test Signal Generator User Manual
