LINGUA IR RADIATOR
Overview
1
22
4
7 7
6
5
6
3
4
77
Figure 1-4 Front, back, and top view of Lingua IR radiator
1.
Status LED: consists of three multicolor LED lights that show the radiator status and other radiator
related information.
2.
Infrared LEDs: the LED lights that transmit the IR signal. Adjust the intensity by changing the power
settings.
3.
Mains connector
