Televic LINGUA IR - Radiator Power Levels; Radiator LED Status Meaning

4.
IR signal connector: connect to transmitter or other radiator using a RG59 coax cable with BNC
connectors.
5.
VESA mounting holes: compatible with all VESA 100×100 mounts
6.
Safety eye: for additional security to mount the radiator
7.
Cooling fins: to cool the radiator during usage
Radiator Power Levels
The Lingua IR radiator has four different power modes, which you can set using the web server. You can use
different power levels to increase the life span of the infrared LEDs (by reducing the power level) or to
increase the range of your infrared signal (by increasing the power level). The following power levels are
available:
Power level Description
Power off No power
Reduced power Power at 33% of its maximum capacity
Normal power Power at 66% of its maximum capacity
Boost power Power at 100% of its maximum capacity. Beware that when you use the
radiator at this power level this reduces the life span of the infrared LEDs.
Radiator LED Status Meaning
LED status Meaning Remark
Middle LED red Power OK, but there is no signal
Middle LED Green Power on, signal present
Middle LED Orange
Power on, signal present
Synchronization error
Middle LED blue Calibration started
Right LED green Calibration successful
Right LEDred Calibration failed All IR LEDs are forced to
power off
LING UA IR RADIATO R 25
