Televic LINGUA IR - Prepare Radiator For Mounting

(F) x 2
(E)
(G) x 2
set screw
side view
4
5
3
6
Figure 1-18 How to mount the Lingua RAD mount onto the wall
Prepare Radiator For Mounting
To attach the radiator to the wall, you first need to remove the faceplate from the mount and attach it to
the radiator. Follow the instructions below to prepare the radiator:
1. Remove quick release faceplate from mount by pulling quick release lever and sliding faceplate off
mount.
quick release lever
1
1
Figure 1-19 How to remove the faceplate from the mount
MOUNT THE RADIATO RS 47
