Televic TCS5500 - DCS5500 Connection Cable; System Connection Cables (ID5500;INT5500)

Page | 98
DCS5500 Connection Cable (Shielded)
All DCS units are connected to the interface units with this type of
gray cable. There are cables of 0.5m, 1m, 2m, 3m and 5m.
Cable
Connector
Function
CABLE 4PR.
RJ45-8P
FTP 26AWG CAT.5e
71.67.5105
71.67.5110
71.67.5120
71.67.5130
71.67.5150
Orange/White
1
CLK OUT +
Orange
2
CLK OUT -
Green/White
3
PS
Blue
4
DATA +
Blue/White
5
DATA -
Green
6
GND
Brown/White
7
HP OUT -
Brown
8
HP OUT +
Connection Cable (Shielded) for
ID5500 / INT5500/SPL5525/SPL5501/ Combi
panels
The system cables are needed to interconnect the interfaces
INT5500 , splitters SPL5525 , splitters SPL5501 , interpreter desks
ID5500 and combi panels , and to connect them to the central unit
or extension unit EU5500. Standard cables are available in lengths
of 2m, 5m, 10m and 20m. Only cables from the central equipment
room to the conference room need to be made according
underneath cabling scheme.
These cables have a yellow color.
