Tenda O6 User Manual

Web UI Functions
-70-
Parameter description
Parameter
Description
Internal IP
IP address of intranet server.
Internal Port
Service port of intranet server. During settings, automatic filling is performed after Public
Service is selected.
External Port
Port that is open to the user to access. During settings, automatic filling is performed after
Public Service is selected.
Protocol
Protocol type of a corresponding service. If you are not sure about protocol type of a service
during settings, you are recommended to select TCP/UDP.
Operation
After successfully setting rules, click to delete corresponding rules.
Application scenario
A community uses 06 to perform networking. AP1 works in router mode and is connected to the Internet. AP2 is
bridged to AP1 wireless signals in station (client) mode. The AP1 WAN IP address is 202.105.106.55. The network
administrator needs to access resources on the intranet computer during business trip. This can be achieved
through the port forwarding function. Establish and enable an FTP server on the intranet computer. Store
resources to be accessed on the server. Set the port forwarding function on 06.
Assume that basic information about the FTP server is as follows:
IP address
192.168.2.100
User Name and
Password
admin
Port
21

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
