Tenda O6 User Manual

Web UI Functions
-71-
The reference topological graph is as follows:
Tip
 Ensure that the AP WAN port has obtained a public network IP address.
 If the AP WAN IP address is dynamically changed, refer to relevant contents of DDNS.
 An intranet computer IP address must be manually configured to avoid service interruption due to automatic
change of IP address.
 System firewall, some pieces of antivirus software, and security software may prevent other computers from
accessing the server on the computer. You are recommended to disable them temporarily when using this
function.
Configure port forwarding
1. Log in to the device’s web UI.
2. Go to Advanced > Port Forwarding.
3. Click Add.

Tenda O6 Specifications

General

Internal	No
Placement	Wall
Reset button	Yes
Certification	FCC/CE/RoHS
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Channel bandwidth	35 MHz
Transmitting power	1 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	433 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Input current	0.5 A
AC input voltage	24 V
Power consumption (max)	9 W
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	16 dBi
USB 2.0 ports quantity	0
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	67.5 mm
Width	94.9 mm
Height	270 mm
