24-Port Managed Gigabit Switch
Mirroring Port Configuration
The following table is used for Rx and Tx enabling.
Port
The logical port for the settings contained in the same row.
Mode
Select mirror mode.
Rx only Frames received at this port are mirrored to the
mirrorin
g port. Frames transmitted are not mirrored. Tx only
Frames transmitted from this port are mirrored to the mirroring
port. Frames received are not mirrored. Disabled Neither
frames transmi
tted or frames received are mirrored. Enabled
Frames received and frames transmitted are mirrored to the
mirror port.
Note
：
A fast port can not be mirrored onto a slower port. For example,
trying to mirror the traffic from a 100 Mbps port onto a 10Mbps
port can cause throughput problems. However, keeping an
equal speed between the two ports is allowed.
106
