Tenda TEG3224T User Manual

24-Port Managed Gigabit Switch
The delay used by STP Bridges to transition Root and
Designated Ports to Forwarding (used in STP compatible
mode). Valid values are in the range 4 to 30 seconds.
Protocol Version
The STP compatible and normal mode setting. Compatible
means the Switch works in compatible mode; Normal means
the Switch works in RSTP mode.
Note
：
1. Hell
o time can’t be configured, 2s by default.
2. The Hello Time cannot be longer than the Max. Age. Otherwise
a configuration error will occur. Observe the following formulas
when setting the above parameters:
Max. Age ≤ 2 x (Forward Delay - 1 second)
Max. Age ≥ 2 x (Hello Time + 1 second)
3.6.4 RSTP Port Configuration
Please select the left meun as TEG3224T→Configuration→
Spanning Tree→ Port to enter the following window:
36
