24-Port Managed Gigabit Switch
Root Cost
Root Path Cost. For the Root Bridge this is zero. For all other
Bridges, it is the sum of the Port Path Costs on the least cost
path to the Root Bridge.
Topology Flag
The current state of the Topology Change Flag for this Bridge
instance.
4.4.2 RSTP Port Status
Please select the left meun as TEG3224T→Monitor→Spanning
Tree →Port Status to enter the following window:
The page displays the RSTP port status for port physical ports in
the currently selected switch.
RSTP port status is:
Port
The switch port number of the logical RSTP port.
122
